Modelo |
PMT-1648 |
PMT-1654 |
PMT-2063 |
PMT-2473 |
PMT-3092 |
|
Dimensiones de la mesa (mm) |
400x1220 |
400x1370 |
500x1600 |
610x1854 |
760x2330 |
|
Peso admitido sin la mesa (TN) |
0.9 |
1.0 |
1.2 |
1.5 |
1.6 |
|
Recorridos x, y, z (mm) |
|
Con guarda completa |
762x508x600 |
100x508x600 |
1270x720x600 |
1520x720x700 |
2032x939x700 |
|
Con protección de mesa |
762x453x600 |
100x453x600 |
1270x705x600 |
1520x705x700 |
2032x874x700 |
|
|
|
Cono de husillo |
NT/BT/CAT40 |
BT/CAT40 |
|
Velocidades del husillo (rpm) |
UH:HIGH RANGE:521-4200 UL:HIGH RANGE:721-4200 |
|
F:HIGH RANGE:721-4200 LOW RANGE:60-520RPM LOW RANGE:60-720RPM |
|
LOW RANGE:60-720RPM R:50-6000RPM |
|
Potencia motor |
UL:5HP R:10HP |
UH F:7.5 HP R:10HP |
R:10HP,15HP (OPT.) |
|
Ancho de la guía eje Y (mm) |
460 |
600 |
700 |
|
Ancho de la guía eje Z (mm) |
300 |
350 |
350 |
|
Distancia del centro del husillo a la columna (mm) |
RIGID HEAD(R): 530 TURRET MILLING HEAD(UL): 520 |
RIGID HEAD(R): 760 TURRET MILLING HEAD(UH,F): 640 |
RIGID HEAD: 900 |
|
Distancia husillo/mesa (mm) |
100-700 |
100-700 |
100-800 |
100-800 |
|
Potencia motor x, y, z |
1KW |
1.2 KW |
1.8KW |
1.8 KW |
|
Peso de la máquina (kg) |
2300 |
2400 |
3700 |
4100 |
7000 |
